Stonex SC600 GNSS Receiver – User Manual
8
2. Technical Specification
2.1 GNSS
 Channels：555
 Tracking signals
Satellite Signals
GPS L1 C/A, L2P
GLONASS L1 C/A, L2P
BDS B1, B2
Galileo E1, E5b
QZSS L1 C/A, L1C, L2C, L5
SBAS L1, L5
 Update Rate: 5Hz Standard (20Hz Optional)
 Timing accuracy: 20ns
 Maximum Speed: 1,850 km/h

2.2 Physical
 Weight: 550g
 Dimensions: 150mm x 105mm x 34mm
2.3 Environmental
Operating temperature -30
℃
~+65
℃
Storage temperature -40
℃
~+80
℃
Dust and water protection IP67
Drop
Designed to endure to a 1.5 m free drop on
concrete floor with no damage
Vibration Vibration resistant
