Data badge - Lower part of front frame
Type of gas
This cooker must only be used with Natural
Gas only, as specified on the appliance
data badge.
Gas category
Natural Gas - I
2H
Pressure setting
G20 Natural Gas @ 20 mbar
Pressure test point
Use the oven injector
Aeration
Fixed
Grill - Grill burner is surface combustion
type. Spark gaps 3 - 4mm.
Hob - Burners have burner heads and
caps which are removable for cleaning.
Concealed electrodes to each burner.
Ovens - Oven burners are sheet steel,
with pierced ports in stainless steel flame
strip. Spark Gap: 3 - 4mm. Flame super -
vision: Expansion type. Thermostat phial:
Front centre of oven roof.
Electrical supply
220 - 240V ~ 50Hz
Spark generator: Mains operated 7 outlet
controlled by a single push button switch at the
left hand side of the facia to individual
electrodes.
Warning: This cooker must be earthed.
Appliance class
Class 1, Freestanding
Countries of destination
GB - Great Britain, IE - Ireland
31
Gas Burner Nominal Injector
Grammes per hour
Rate Qn Size Butane Propane
Natural Grill 2.4kW 115 - -
Gas Hob - LHF 1.0kW 77 - -
Hob - LHR & RHR 2.0kW 104 - -
Hob - RHF 3.0kW 130 - -
Main Oven 2.5kW 180 Amal - -
Top Oven 1.75kW 110 Amal - -
Maximum heat input Qn 12.9kW - - -
TECHNICAL DATA
