37
3:e Axel 3:rd Shaft 3:e Welle
Pos Art. No. Benämning Description Benennung Note
1 2A08931 Spindelaxel Spindle shaft Spindelwelle
2 3K01186 Kil Key Keil 5x5x18
3 2HSB7501-1 Kugghjul Gear wheel Zahnrad z18-1,5
4 2D00008 Distans Spacer Distanz 17x6,5
5 3L11003 Kullager Ball bearing Kugellager 6203
6 2D17002 Distans Spacer Distanz 17x2
7 2X08908 Kugghjul komplett Gear wheel comp. Zahnrad komplett z47-1,5
8 3K00197 Kil Key Keil 5x5x50
9 3K00187 Kil Key Keil 5x5x20
10 2T08955 Kopplingsklo Clutch Kupplungsklaue
11 2X08909 Kugghjul komplett Gear wheel comp. Zahnrad komplett z62-1,5
12 2D00009 Distans Spacer Distanz 17x3,5
13 3C01117 Spårring Circlip Sicherungsring SGA 15
14 3L16002 Kullager Ball bearing Kugellager 6302
