38
2:a Axel 2:nd Shaft 2:e Welle
Pos Art. No. Benämning Description Benennung Note
1 2A04871 Axel Shaft Welle
2 3L11003 Kullager Ball bearing Kugellager 6203
3 2D17002 Distans Spacer Distanz 17x2
4 2X08574 Kugghjul komplett Gear wheel comp. Zahnrad komplett z79-1,5
5 3K00912 Kil Key Keil 5x5x48
6 2T08954 Kopplingsklo Clutch Kupplungsklaue
7 2X08906 Kugghjul komplett Gear wheel comp. Zahnrad komplett z47-1,5
8 2D17003 Distans Spacer Distanz 17x3
9 2D00012 Distans Spacer Distanz 17x29,5
10 3K01186 Kil Key Keil 5x5x18
11 2H08905 Kugghjul Gear wheel Zahnrad z32-1,5
12 2D17005 Distans Spacer Distanz 17x5
13 3L11003 Kullager Ball bearing Kugellager 6203
