Strautmann EK 1107 - Page 32

Remedying Faults in PP 1207–Klöckner Möller
Remedying faults PP 1207
page 32 –April 2005
The "small NG6" valve must be
checked.
4.1 Bale cannot be ejected
D. Valve sticking
E. Coil plug faulty
F. Valve coil faulty
C. Actuate hydraulic
valve by pressing in a
blunt object, e.g. an
Allen key
Check valve for
smooth movement and
replace if necessary
E. Check valve coil
plug and replace if
necessary
D. Check valve coil by
using an ohmmeter : If
the resistance is more
than 100kohms the coil
is faulty, tappet is no
longer actuated.
Replace coil.
