Lisa Compact 77
Short description
Config server
Connection to the configuration update server. Not applicable for
fixed configuration mode.
SW (=software) update server
Connection to the software update server
Schedule server
Connection to the schedule update server
PL (=playlist) update server
Connection to the playlist update server
Monitoring server
Connection to the remote monitoring server
Proxy server
Connection to the proxy server
There are four possible result values for each connection, each represented with a single letter
abbreviation:
Abbreviation
Full result
Meaning
S
Success
The device supports this feature, the feature is enabled and the
device can connect to the server
F
Failure
The device supports this feature, the feature is enabled but the
device cannot connect to the server
E
Empty URL
The device supports this feature, the feature is enabled but the
URL for the specific resource is “empty”
N
Not applicable
Either the device does not support the feature, or the feature is
disabled or not applicable for the specific configurations
17.3.2
Interpreting connection test results
The following list presents suggested interpretations for common combinations of results. However, other
combinations may occur and need careful interpretation/analysis.
· Proxy server shows F (=failure): The Lisa is configured to use a proxy server, but cannot connect
to it. That means all internet connections will fail. First check with your network administrator whether
a proxy server must be used. If so, make sure the connection with the proxy server can be made and
test again. See also Using a proxy server.
