V
Replacement Parts
ulcan
- 30 -
ITEM QTY P/N DESCRIPTION ITEM QTY P/N DESCRIPTION
1 1 440002 FACE CAP 19 1 440040 BODY/HANDLE ASSY., YELLOW
2 1 440033 O-RING, FACE CAP 1 440040-6 BODY/HANDLE ASSY., GREEN
3 1 440070 REFLECTOR/LENS ASSY. 20 1 440102 COVER, CHARGE RACK YELL.
4 2 440023 SCREW, BATTERY CLAMP 440102-6 COVER, CHARGE RACK GRN
5 1 440005 CLAMP, BATTERY 21 1 450022 SPRING, LATCH RELEASE
6 1 440006 PAD, BATTERY CLAMP 22 1 900047 SCREW, 4-24 X 1/2 PHILLIPS
7 1 44007 BATTERY 23 1 440115 PCB, STANDARD
8 1 440116 BOOT, SWITCH 440114 PCB, VEHICLE MOUNT
1 440116-1 BOOT, D.F. SWITCH (GREY) 24 1 440106 LATCH, CHARGER
9 1 440008 PCB ASSY, STD TOGGLE 25 1 440101 HOUSING, CHARGER YELLOW
440027 PCB ASSY, D.F. TOGGLE 440101-6 HOUSING, CHARGER GREEN
10 1 440046 O-RING, BODY
11 1 44913 BULB, 8W BI-PIN
44912 BULB, 6W DUAL FILAMENT
12 1 44009 KIT, CONTACT SCREW
13 1 44012 KIT, SWITCH MECH W/LOCK
44013 KIT, SWITCH (SHOWN) NOT SHOWN:
14 1 45232 STRAP ASSY, SHOULDER 22311 CORD, 120V AC CHARGE
15 2 440018 CLIP, SHOULDER STRAP 21725 CORD, 230V AC CHARGE
400262 D-RING (NEW STYLE) 22666 CORD, 100V AC CHARGE
(OLD STYLE - NOT SHOWN) 22241 CORD, 240V AC CHARGE
17 1 440015 PLUG, VALVE 22051 CORD, 12V DC CHARGE
18 1 130018 VALVE 440040 BODY/HANDLE ASSY., YELLOW
440040-6 BODY/HANDLE ASSY., GREEN
