Ground connection cable (black - 6 mm²) for compressor
• Strip the insulation from the cable.
• Connect the cable with the supplied ring cable lug.
• Attach the ring cable lug to a suitable ground point on the vehicle (observe manufacturer‘s
specications).
Battery connection cable (red - 6 mm²) for compressor
• Strip the insulation from the cable.
• Strip both cable ends of the supplied fuse holder (6 mm²).
• Connect the cable of the main harness with the supplied shrink joint connector and the cable of
the fuse holder.
• Connect the other end of the fuse cable to the supplied ring terminal.
• Connect the ring terminal to the positive (+) terminal of the battery.
Installation cable set
Connection cable switched positive from ignition start switch (red - 0.75 mm²)
• Strip the insulation from the cable.
• Connectthecabletothepre-assembledbuttconnectorontheatfuseadapter(yellowcable).
4. Fuses
Fuse for battery connection cable (red - 1.5 mm²)
• Insertthesupplied10Afuseintothefuseholderandclosetheapofthefuseholder.
Fuse for battery connection cable (red - 6 mm²)
• Insertthesupplied40Afuseintothefuseholderandclosetheapofthefuseholder.
Fuse for connection cable switched positive from ignition start switch (red - 0.75 mm²)
• Remove a minimum 10 amp fuse from a wiring harness in the fuse box that carries switched
positive from the ignition start switch (terminal 15).
• Plugintheatfuseadapter.
• Insert the supplied 10 A fuse and the original fuse in the locations provided.
Installation cable set
Do not use any power source other than switched positive from the ignition start switch
(terminal 15).
The cable harness can only supply power to one compressor. When installing two
compressors, a second power connection cable is required. Contact a
STREETEC dealer to purchase the optional wiring harness for the second
compressor (part number: 1160 00 00).
3. Connection of the wiring harness to the ignition
