STREETEC autoleveling - Air Line Assembly and Disassembly

Assembly air line /  tting
1. Cut the air line at right angles and free of burrs. Make sure that the air line has no sharp edges,
longitudinal grooves or other damage.
2.Inserttheairlineintothettingasfarasitwill
go.Theretainingelementxestheairlineinthe
tting.Thebuilt-inO-ringcreatesapermanently
tight connection.
3. Check whether the hose is correctly inserted.
This is easily done by pulling on the air line. In
this way, you can check the holding function and
ensure that no leakage has occurred.
Disassembly air line /  tting
1. Make sure that there is no pressure on the
system. If the system is still under pressure,
release it.
2.Pushbacktheretainingelementofthetting
withyourngersorwiththeaidofareleaseaid
and hold it in this position.
3. The air line can now be removed.
Use the included hose cutter (part number: 9909 2 0266)
to create a clean, burr-free, square cut edge.
Abb. 38: Hose cutter
Abb. 39-40: Plugging in the air line Abb. 41: Checking the plug connection
Abb. 45: Removing the air line
Abb. 42: Checking the system pressure Abb. 43-44: Unlocking the retaining element
