1. Select a mounting location for the component. The mounting location should be dry and allow the
ECU to be held securely.
2. Check that you can guide the cable harnesses to the intended location.
3. UsethesupplieddrillingtemplatetodrilltheholesiftheECUistobemountedlyingat.
4. ConnectthewiringharnessesbeforexingtheECU.Thiswillmaketheworkalittleeasier.
5. Then attach the ECU directly to a surface or to the bracket.
The ECU (Fig. 1) of the STREETEC autoleveling consists of a high-quality aluminum housing with a
high-gloss acrylic glass cover. We recommend handling the ECU carefully during installation so as not
to impair its optical properties.
TheECUmustbermlyscrewedintothevehicle.Otherwise,calibrationmaynotbe
carried out accurately and control problems may occur!
Inthescopeofdeliveryyouwillnd a drilling template for easy positioning and
mounting of the ECU!
Abb. 1: STREETEC autoleveling - ECU
The ECU is designed to be mounted in the vehicle in several ways:
• lyingatwithcompletelyhiddenwiring
• screwed to a holder (a holder is included in the scope of delivery with which the ECU can be
mounted upright).
