STREETEC autoleveling - Touchscreen; Touchscreen Technical Data and Dimensions

Touchscreen
The touch screen of the STREETEC autoleveling has numerous technical innovations that give the
system a very special value!
• The capacitive touchscreen works according to the same principle as a smartphone. Commands
are only made via touch without pressure.
• The system supports multi-touch mode. This allows different functions to be executed
simultaneously or in combination.
• A haptic feedback creates the impression of pressing real keys.
• Dimming when the driving lights are on increases safety when driving at night.
• Theuserinterfaceisindividuallycongurableforupto3differentusers.
The control panel (touch screen, Fig. 2) of the
STREETEC autoleveling consists of a
highquality aluminum housing with integrated
neodymium magnets.
With the help of the integrated magnets, the
control panel can be easily attached to all
magnetic parts in the vehicle.
The touchscreen has a USB-C port for
connecting to the harness.
Abb. 2: STREETEC autoleveling - Touchscreen
The USB-C port only works when the plug is inserted the right way round. If the
control unit indicates a communication error, the plug must be rotated! Optionally,
the control panel can be connected with the supplied angled USB-C plug. In this
case, the connection direction is irrelevant.
Product details
Technical data - Touchscreen
Product STREETEC autoleveling - Touch Pad
Item number 2013 0 0003
Weight 135 g
Elektrische Details
Nominal voltage 5V
Dimensions (L x W x H) 114,5 mm x 71 mm x 10,2 mm
max. current 500 mA
10,2 mm
80°
71 mm
114,5 mm
10,2 mm
R3,2 mm
Dimensions
