Installation cable set
The wiring harness can be routed in or under the vehicle. In any case, make sure that all parts of the
wiring harness are protected from abrasive edges and heat sources.
Installation cable set
Remove all fuses of the STREETEC autoleveling when bridging the vehicle or
welding on the vehicle. Failure to do so could result in damage to the system.
2. Connection of the wiring harness to the battery and vehicle ground
Ground connection cable (black - 1.5 mm²) for ECU and valve block.
• Strip the insulation from the cable.
• Connect the cable with the supplied ring cable lug.
• Attach the ring cable lug to a suitable ground point on the vehicle (observe manufacturer‘s
specications).
Battery connection cable (red - 1.5 mm² ) for AirCU and valve block
• Strip the insulation from the cable.
• Strip the insulation from both cable ends of the smaller of the two fuse holders supplied (1.5mm²).
• Connect the cable of the main harness with the supplied shrink joint connector and the cable of
the fuse holder.
• Connect the other end of the fuse cable to the supplied ring terminal.
• Connect the ring terminal to the positive (+) terminal of the battery.
1. Connection of the AirCU, valve block and compressor
• Connect the wiring harness to the ECU.
• Connect the plug of the valve block to the designated plug of the main wiring harness.
• Strip the insulation from the compressor cables (red/black - 6 mm²) and the counterparts on the
main wiring harness (red/black - 6 mm²).
• Connect the stripped compressor cables to the stripped compressor connection cables of the main
harness; use the supplied shrink butt connectors for this purpose.
Disconnect the starter battery before installing the cable set.
Make sure that the cables are laid properly.
