Strobel 141-40 - Technical Data

7 BA_141-30-40_A6-7_140416_en
2.4
Number of stitches: Max mechanically admissible
Technical Data
Cl. 141-30 2800 min
-1
Cl. 141-40 4200 min
-1
Recommended rated speed:
Cl. 141-30 2300 min
-1
Cl. 141-40 3600 min
-1
Machine pulley diameter dw 80 mm
V-belt profile 10 x 6 mm
Stitch length Cl. 141-30 3 - 6 mm adjustable
Cl. 141-40 0.6 – 2.5 mm adjustable
Kind of stitch Single Thread Overseam
Needle system 459R
Needle size Cl. 141-30 110 - 130
Cl. 141-40 40 - 120
Recommended thread twisted polyester filament
Recommended thread size
Cl. 141-30 50 -10
Cl. 141-40 130 – 80, 40 - 10
Stitch type 501
Kind of feed rear cup drive
Pneumatic connection 10 bar
Operating pressure 5 – 6 bar
Required space 0.6 m x 1.06 m
Noise:
Average noise level at a speed of
Cl. 141-30 n = 2300 min
-1
LpAm 84 dB(A)
Cl. 141-40 n = 3200 min
-1
LpAm 85 dB(A)
Noise test according to DIN 45635-48-1 KL3
