Strobel 141-40 - Installation and Putting into Service; Installation

8 BA_141-30-40_A6-7_140416_en
3
3.1
Installation and putting into service
Strobel machines are supplied either as complete units with head, stand and
motor, or head with motor only, or the head only.
Unpacking the machine
Due to the high weight and to avoid damages during transport, complete units
are packed in several smaller cartons.
Machine head and motor are removed from the stand. Reel stand, rods, oil and
other accessories are packed into the stand packing. Make sure that all
accessories have been unpacked before throwing away any packing material.
3.2 Installation
ATTENTION!
Danger of bodily injuries or finger bruises through pulling in
of garments or hairs!
The machine may not be operated without belt guards for
head and motor.
Caution: Screw oil drain pipe 133.0764 to the lid 112.0085 before setting the
top part on the table top. (See point “5.1“)
If the frame is not delivered by us as well, but rather the machine set on a
different frame, then the table top needs to be prepared as can be seen in the
table-top diagram.
ATTENTION!
Before putting the machine into service make sure
that the electrical connecting data on the motor’s
name plate, your electric network, and all other connecting
values, e. g. for the air, correspond to
the data shown on the machine and the operating
instructions.
