20 BA_141-30-40_A6-7_140416_en
4.7
Inserting and removing the material (Fig. 11)
ATTENTION! Danger!
The operating personnel should observe the sewing range
carefully during swing. Otherwise danger of finger bruises
and needle throughstitches.
When the machine is in standstill position and the needle is placed approx. 3
mm within the feed cup, by opening the front cup up to approx. 14 mm, by
either actuating the treadle or the pneumatic cup opening (depending on the
machine class) the sewing material can be inserted or removed easily.
Put the sewing material edge to edge and place it then up to the height limit
stop of the material guide, close the front cup and start sewing.
When using a stop motor the needle is positioned automatically after the
sewing process when heeling the treadle.
Only then the thread can be torn over the edge of the feed cup and then the
material can be removed, or the material is removed and the thread is cut using
scissors.
