Adjusting instructions in brief
Plunger stops to the needle needle point 5 mm after centre plunger
Transport length lower transport 2 – 6 mm
Transport length upper transport  position on (1) (Fig. 9) 2 – 5 mm
 position on (1) (Fig. 9) 4 – 7 mm
Transport start at 6 mm transport length needle point 3 mm
after centre plunger
Transporter position back 4 mm air to the presser plate
Upper transport start to lower transport synchronized
Presser plate lift (basic position) 5 mm
Presser plate lifts needle point 10 mm before centre
plunger (return path)
Venting value between presser plate 11 mm
and stitch plate
Side presser lift 4.5 mm
Side plunger path 4.5 +0.2 mm
Upper dead point side plunger cam needle point 7 – 8 mm before side
plunger centre
At stitch plate contact of the plunger crank movement results
stop levers and response of the upper 0.15 mm above thread M5,
dead point of the side plunger cam upper plunger lies against
fabric support surface
Position of the eccentric bolt 46° to the vertical
Pusher position horizontal
Interval stroke 4.8 ±0.2 mm
Setting value of hook point 2 ±0.2 mm
to the needle eye
Distance guide block to 2 mm
plunger guide plate
Loop stroke 2 mm right needle position
Number of spot tacks 2 – 4 stitches
