13 BA_VEB100-2-4-5_A5-3_230118_en.doc
3 Setup and installation
3.1 Unpacking the machine
Strobel machines are delivered either complete or as a machine head with sewing
drive.
Reel stand, rods and other accessories are packed into the packing.
Make sure that all accessories have been unpacked before throwing away any packing
material.
3.2 Setting up the machine
C A U T I O N ! Danger of injury!
Entanglement hazard for clothing or hair and Danger of finger
injuries!
Never operate the machine without the belt guards for the upper
part and Sewing drive.
If the machine head is supplied without stand first make the borings into the table top
as shown in the drawing. Mount rods and treadles and electric connections according
to the connecting diagram.
The upper component must be fastened to the provided rubber plate on the table top.
Mount the lifting and sewing drive operating rods.
Using a compact motor means to assemble the control box and speed controller under
the table. Also the operating rod between speed controller and pedal has to be
connected.
After assembling the single parts of the reel stand mount it to the right hand side of
the tabletop.
Make sure that all screws on the stand are tight and retighten them, if necessary.
