16 BA_VEB100-2-4-5_A5-3_230118_en.doc
3.4.2 Machine positions
C A U T I O N ! Danger of injury!
Entanglement hazard for clothing or hair and danger of finger
injuries and needle punctures! When checking the positions
while the machine is turned on, keep your fingers and hands
away from moving parts.
Machine with or without thread trimmer:
The machine needs a needle position and a reference position.
Reference position t 08 10:
The reference position must be set in such a way, that the point of the needle in
direction of the insertion stitch closes with the right (inner) edge of the needle
slide plate.
Fig. 2
