30 BA_VEB100-2-4-5_A5-3_230118_en.doc
5.3 Placing and removing the fabric - sewing process
- Knee lever lifting
Lift the cloth support arm by pressing the knee lever.
Place the fabric under the stitch plate and release the pedal.
Press the pedal to start sewing.
When the pedal is depressed, the machine runs at the set maximum speed.
- Pneumatic lifting (optional extra)
Fig. 11 shows the treadle's switching functions when the machine is equipped
with pneumatic lifting. Place the fabric under the stitch plate while the cloth
support arm is lifted and close the arm by slightly pressing the treadle (+1).
The machine is now ready to sew.
If the fabric is not placed correctly, the cloth support arm can be lifted again by
heeling the treadle back into its initial position. At the end of the sewing process
the thread trimmer (optional extra) is operated and the cloth support arm is
lifted by heeling the treadle (-1).
