6. Materials list
6.1 Main PCB materials list
cc Quantity Reference Part Number VENDOR
1 1 PCB-MAIN ; IT612_R1.8 VER 1.8, 2Layer
2 3 BD1,BD2,L15 CORE-FERRITE BEAD ; FCM2012C-101,100ohm TAI-Tech
3 7 BD6,BD9,BD24,BD3,BD4,BD5,BD7 CORE-FERRITE BEAD ; SMB403025 TAI-Tech
4 4 L4,L5,L6,L7 INDUCTOR-SMD ; FCI1608-1R8K,1608 SIZE TAI-Tech
5 7 L1,L2,L3,L10,L12,L13,L14 INDUCTOR-SMD ; 10uH, 10%, 2012 TAI-Tech
6 20 R8,R9,R16,R23,R35, R-CHIP ; 1Kohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
R84,R90,R96,R98,R100,
R103,R107,R116,R122,R148,
R149,R162,R173,R176,R177
7 28 R13,R17,R19,R20,R27,R32, R-CHIP ; 4.7Kohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
R33,R34,R49,R50,R57,R60,R125,
R128,R140,R144,R145,R146,
R147,R150,R151,R152,R153,
R156,R159,R167,R142,R143
8 12 R36,R85,R89,R129, R-CHIP ; 10Kohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
R130,R139,R141,R171,R172,
R175,R178,R179
9 2 R163,R164 R-CHIP ; 100ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
10 3 R14,R15,R51 R-CHIP ; 3.3Kohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
11 1 R18 R-CHIP ; 10ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
12 11 R21,R22,R24,R37,R38,R55, R-CHIP ; 0ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
R123,R124,R126,R127,R166
13 1 R28 R-CHIP ; 150ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
14 2 R30,R29 R-CHIP ; 18ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
15 1 R31 R-CHIP ; 200ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
16 15 R39,R97,R99,R104,R108,R115, R_CHIP ;75ohm, 1%, 1/16W, DA, TP, 1608 HAN RYUK
R40,R41,R43,R44,R45,R46,R47,R42,R95
17 4 R102,R168,R169,R192 R-CHIP ; 6.8Kohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
18 5 R3,R4,R161,R160,R121 R-CHIP ; 33ohm, 5%, 1/16W, DA, TP, 1608 HAN RYUK
19 1 R131 R-CHIP ; 15Kohm, 1%, 1/10W, DA, TP, 2012 HAN RYUK
20 1 R132 R-CHIP ; 33Kohm, 1%, 1/10W, DA, TP, 2012 HAN RYUK
21 1 R133 R-CHIP ; 5.1Kohm, 1%, 1/10W, DA, TP, 2012 HAN RYUK
22 1 R134 R-CHIP ; 20Kohm, 1%, 1/10W, DA, TP, 2012 HAN RYUK
23 1 R135 R-CHIP ; 300ohm, 5%, 1/10W, DA, TP, 2012 HAN RYUK
24 1 R137 R-CHIP ; 47ohm, 5%, 1/10W, DA, TP, 2012 HAN RYUK
