Strong SRT4355 User Manual

52 4 C31,C34,C37,C40 C-CERAMIC, CHIP ; 270pF, 5%, 50V, NPO, TP, 1608 SAMWHA
53 4 C33,C36,C39,C42 C-CERAMIC, CHIP ; 330pF, 5%, 50V, NPO, TP, 1608 SAMWHA
54 8 C127,C128,C129,C130,C131, C-CERAMIC, CHIP ; 470nF, +80-20%, 16V, Y5V, TP, 2012 SAMWHA
C132,C133,C134
55 5 C10,C13,C16,C21,C22 C-CERAMIC, CHIP ; 1000pF, 5%, 50V, X7R, TP, 1608 SAMWHA
56 1 C7 C-CERAMIC, CHIP ; 1500pF, 10%, 50V, X7R, TP, 1608 SAMWHA
57 1 C1 C-CERAMIC, CHIP ; 1uF, +80-20%, 16V, Y5V, TP, 1608 SAMWHA
58 1 C2 C-CERAMIC, CHIP ; 51pF, 5%, 50V, COG, TP, 1608 SAMWHA
59 2 C11,C12 C-CERAMIC, CHIP ; 10nF, 10%, 50V, X7R, TP,1608 SAMWHA
60 2 D1,D2 DIODE-SWITCHING ; RLS4148,100V,450mA,LL- Rohm
61 4 Q33,Q34,Q37,Q513 TR-SMALL SIGNAL ; KST3904-MTF,NPN,-60V,- SAMSUNG
62 11 Q4,Q5,Q7,Q9,Q10,Q26,Q28, TR-DIGITAL ; DTC114EKA,NPN,100mA,200mW,SC-59 Rohm
Q29,Q30,Q31,Q38
63 1 U1 IC-MICROPROCESSOR ; L64108-54 MIPS/XPORT,240PIN,QFP LSI logic
64 1 U2 IC-FLASH MEMORY ; SST39VF800A-90-4C-EK,1MX8BIT,TSOP,48P,3.3V SST
65 1 U3 IC-DRAM ; KM416V1204CJ-6 or 7,1MX16BIT,SOJ,42P,3.3V SAMSUNG
66 1 U8 IC-SDRAM ; KM416S1020CT-G7 or 8 or 10,512KX16BIT,TSOP,50P,3.3V SAMSUNG
67 1 U4 IC-EEPROM ; AT24C64N-10SC-2.7,64KBYTE,SOIC,8P,3.3V ATMEL
68 10 U21,U22,U25,U26,U27, IC-CMOS LOGIC ; MM74HCT244MTC Fairchild
U28,U29,U30,U31,U32
69 1 U20 IC-CMOS LOGIC ; MM74HCT245MTC Fairchild
70 1 U6 IC-CMOS LOGIC ; 74LCX04M,LOW VOLTAGE HEX INVERTER,SOP,14P Fairchild
71 1 U23 IC-PLD ; EPM3032ALC44-10 (PLCC) ALTERA
72 1 U11 IC-VIDEO ENCODER ; BT864AKRF,NTSC/PAL DIGITAL VIDEO ENCODER,PQFP,52P Rockwell
73 1 U13 IC-D/A CONVERTER ; AK4323VF-E2,20BIT,VSOP,24P AKM
74 1 U15 IC-AUDIO/VIDEO SWITCH ; CXA2126Q Sony
75 1 U9 IC-TRANSMITTER/RECEIVER ; SP232ECN,SOIC,16P SIPEX
76 1 U5 IC-RESET ; DS1811-10, SOT-23,3P ILSSAN
77 1 U10 socket SOCKET-IC ; 3262-44-T,PLCC ILSSAN
78 1 U7 IC-A/V DECODER ; L64005F LSI logic
Item
Quantity Reference Part Number VENDOR
1 2 E8,E9 C-AL ; 47uF/50V-6.3*11*5, FORMING CUT TYPE SAMWHA
2 1 E53 C-AL ; 220uF/16V-8*11.5*5, FORMING CUT TYPE SAMWHA
3 3 E17,E12,E25 C-AL ; 4.7uF/50V-5*11*5, FORMING CUT TYPE SAMWHA
4 3 E24,E41,E52 C-AL ; 10uF/50V-5*11*5, FORMING CUT TYPE SAMWHA
5 3 E11,E57,E54 C-AL ; 100uF/16V-6.3*11*5, FORMING CUT TYPE SAMWHA
6 4 E7,E16,E40,E51 C-AL ; 47uF/25V-5*11*5, FORMING CUT TYPE SAMWHA
7 20 E1,E2,E3,E4 C-AL ; 10uF/25V-5*7*5, FORMING CUT TYPE SAMWHA
E5,E6,E13,E14,E15,E18,E21,E23,E39,
E43,E44,E45,E47,E48,E49,E50
8 2 E27,E35 C-AL ; 22uF/16V-5*7*5, FORMING CUT TYPE SAMWHA
