1.4. MPEG Transport Stream & A/V Decoding
<Digital Part>
Transport Stream MPEG-2 ISO/IEC 13818 Transport Stream Specification
Profile Level MPEG-2 MP@ML
Input Rate Max. 40Mbit/s
Aspect Ratio 4:3, 16:9
Frame Rate 25Hz for PAL, 30Hz for NTSC
Video Resolution 720x576(PAL),720x480(NTSC)
Teletext Through VBI
Audio Decoding MPEG/MusiCam Layer I & II
Audio Mode Single channel/Dual channel joint stereo/Stereo
Frequency Response 20~20kHz, <+/- 2dB
60Hz~18kHz <+/- 0.5dB
Sampling Rate 32, 44.1, 48kHz
1.5. A/V & Date In/Out
TV Scart Output RGB, CVBS, L, R Output with Volume control
VCR Scart In/Out CVBS, L, R In
CVBS, L, R Out
RCA Output CVBS, L, R Output(Yellow, White, Red Hack) with Volume Control
0V/12V Output RCA Jack Output(Black Jack), Max. 150mA
Data Interface RS-232, Bit Rate: 115200baud
Connector: 9-pin D-sub type
1.6. RF-Modulator
RF-Connector 75w IEC169-2, Male/Female
Frequency 470MHz to 860MHz
Output Channel CH 21-69 for the Demodulator
TV Standard PAL B/G/I/D/K Selectable by Menu Setting
Audio Output Mono with Volume Control
Preset Channel CH 40 (or TBD). Soft ware changeable by Menu screen
