Structural Concepts G Series - Startup: Main Power Switch; Lights Switch; Thermostats

9
STARTUP: MAIN POWER SWITCH / LIGHTS SWITCH / THERMOSTATS
1. Main Power Switch
x Main power switch is at case rear.
x Main power switch controls power to lights AND
thermostats.
x See illustration below.
2. Lights Switch
x When light switch is turned on, all lights in entire
case will turn on.
x See illustration below.
3. Thermostats
x Thermostats are at case rear
x Thermostats control heat to deck and all three
(3) shelves.
x Left thermostat controls heat to deck and
bottom shelf.
x Right thermostat controls heat to middle shelf
and top shelf.
x See next page for thermostat control specifics.
--- Case Rear ---
