Torque item G
to 13 ± 2 ft-lb
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0003-147-000 Hex washer head screw 8
B 0003-364-000 Hex washer head truss screw 1
C 0011-263-000 Washer 2
D 0013-018-000 External tooth lock washer 1
E 0016-049-000 Nylock hex nut 2
F 0016-135-000 Nylock flange hex nut 4
G 0023-288-000 Hex washer head screw 8
H 0023-330-000 Hex washer head screw 4
EN 40
0747-109-002 Rev A.3
