CCoorrnneerr ccoovveerr aasssseemmbbllyy wwiitthh ooppttiioonnaall ppuusshh hhaannddlleess
0746-035-015 Rev A (Head) (Reference only)
0746-035-065 Rev A (Foot) (Reference only)
L
B
D
J
H
A
E
F
F
G
C
K
IItteemm NNuummbbeerr NNaammee QQuuaannttiittyy
A 0023-283-000 Self-tapping screw 4
B 0037-059-000 Heyco hole plug 1
C 0742-201-236 Corner cover, slot 1
D 0742-201-237 Corner cover, hole 1
E 0003-047-000 Hex head cap screw 2
F 0003-050-000 Hex head cap screw 4
G 0016-028-000 Fiberlock hex nut 6
H 0026-012-000 Slotted spring pin 2
J 0748-254-004 Push handle socket, left 1
K 0748-254-006 Push handle socket, right 1
L 1211-351-010
Push handle assembly (page 80) 2
0747-109-002 Rev A.3
79 EN
