RReemmoovviinngg oorr rreeppllaacciinngg tthhee hheeaaddbbooaarrdd
WWAARRNNIINNGG
• Always align the headboard with the deck indicator facing away from the patient and match the litter deck width when
you replace the headboard to avoid the risk of entrapment.
• Do not use the headboard for CPR support.
CCAAUUTTIIOONN -- Do not expand or retract the headboard while a patient is on the product.
You can remove the headboard for patient accessibility and cleaning.
To remove the headboard:
Grasp the handles and lift the headboard straight up and off the product (Figure 12).
FFiigguurree 1122 –– HHeeaaddbbooaarrdd oorriieennttaattiioonn
To expand or retract the headboard:
Grasp the handles of the headboard and pull apart or push together until the headboard is at the desired width of 36”, 42”,
or 48” (A, Figure 12).
To replace the headboard:
1. Align the headboard pegs with the sockets at the head end of the product by using the width labels as a guide (Figure
13).
2. Lower the headboard until it seats into the sockets.
5900-009-001 Rev A.4 21 EN
