Stryker S3 Quick Start Guide

1
3
4 6 8
Nurse Controls: Bed Motion
Push to lower head end/raise foot end of bed.
(Trendelenburg position)
Push to lower foot end/raise head end of bed.
(Reverse Trendelenburg position)
Push to raise bed height.
Push to lower bed height.
Low Height will illuminate on the nurse dashboard
when the bed is at its lowest height.
Push to raise Fowler.
Push to lower Fowler.
Push to raise Knee Gatch.
Push to lower Knee Gatch.
1
3
4
5
6
7
8
2
2
5
7

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
