Stryker S3 Quick Start Guide

Nurse Controls: Bed Motion Locks
Bed Motion Lock*
Locks all motion on bed, including siderail controls and
foot end controls. Button will illuminate when activated.
Fowler 30°+ Lock*
Raises the Fowler to 30° and locks out the Fowler control
at all locations. Fowler 30°+ on the nurse dashboard will
illuminate when activated.
Patient Fowler Lock*
Locks out Fowler control at all siderail locations. The
button will illuminate when activated.
Patient Gatch Lock*
Locks out Gatch control at all locations. The button
will illuminate when activated.
Patient Bed Up/Down Lock*
Locks out Bed Height control at all siderail locations. The
button will illuminate when activated.
* Press and hold the lock button to unlock.
1
3
Note: The Fowler will not go below
30° once the Fowler 30°+ lock is
activated.
4
5
1
3 54
2
2

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
