Stryker S3 Quick Start Guide

Nurse Controls: Main Menu Features
Change Scale Units (lb or kg)
Press the Menu button.
Scroll down using the arrow keys to Scale Units and
press the ENTER button.
Select lbs or kg and press the ENTER button.
To Change Equipment
1. Select Change Equip. in the menu then press and hold
the ENTER button.
2. When the Add/Remove screen appears, add or remove
any equipment.
3. Press the ENTER button
4. Equipment Changed will be displayed when the system
completes the Change Equipment Adjustment. The status
screen will then display the weight of the patient only.
1
3
2
1 3
2

Stryker S3 Specifications

General

Weight Capacity	500 lbs (227 kg)
Maximum Patient Weight	500 lbs (227 kg)
Bed Frame Material	Steel
Type	Hospital Bed
Bed Width	35 inches (89 cm)
Caster Size	5 inches (12.7 cm)
Electrical Requirements	120 VAC, 60 Hz
Width	35 inches (89 cm)
Power Requirements	120 VAC, 60 Hz
Power Backup	Battery backup available
Accessories	IV pole
Siderails	Yes
