+5mm heads are the maximum head
offset allowed for the size 4.
+12mm heads are the maximum
head offset allowed for
the size 5-12 stem.
11
SELECTION OF V40 HEAD TRIAL ON TRIAL NECK
*ForadditionalAcetabularandHeadCompatibilityinformationpleaseseepage17.
Instrument
Figure13
Ensure that the broach cavity and V40
trunnion are clear of debris prior to
assembling the neck and head trials.
Note
Head Trials with an “R” suffix are
made from a radiopaque material,
making them visible on an X-ray.
Note
HEAD HEAD SIZE HEAD OFFSETS
CoCrV40
22 +0, +3, +8
26 -3,+0,+4,+8,+12
28 -4,+0,+4,+8,+12
32 -4,+0,+4,+8,+12
36 -5,+0,+5,+10
40 -4,+0,+4,+8,+12
44 -4,+0,+4,+8,+12
AluminaV40
28 -2.7,+0,+4
32 -4,+0,+4
36 -5,+0,+5
AluminaC-Taper
(whenusedwithC-TaperSleeve–
catalog#17-0000E)
28 -2.5,+0,+5
32 -2.5,+0,+5
36 -5,+0,+5
deltaBIOLOXV40
28 -4,-2.7,+0,+4
32 -4,+0,+4
36 -5,-2.5,+0,+2.5,+5,+7.5
deltaBIOLOXC-Taper
(whenusedwithC-TaperSleeve–
catalog#17-0000E)
28 -2.5,+0,+2.5,+5
32 -2.5,+0,+2.5,+5
36 -5,-2.5,+0,+2.5,+5,+7.5
deltaBIOLOXUniversalTaper(when
usedwithUniversalTaperSleeve-
catalog#6519-T-XXXX)
28 -2.5,+0,+4
32 -2.5,+0,+4
36 -2.5,+0,+4
40 -2.5,+0,+4
44 -2.5,+0,+4
V40 Head Trial
6264-x-xxxR
AssembletheNeckTrialonto
thebroachbyhand.Ensure
thattheengravingonthesuperior
edgeoftheneckisvisible,and
theatlateraledgeoftheneck
trialisalignedwiththeatlateral
edgeofthebroach.Next,assemble
aV40HeadTrialontotheNeckTrial
byhand.
Femoralheadscomeinmultiple
offsets and are different for each
femoralheadimplantmaterial(see
Table4).Forthisreason,nalhead
materialshouldbechosenprior
totrialreduction.Offsetsaddor
subtractfromthebasenecklength
oftheimplantandhelptoachieve
the desired leg length and offset.
Performatrialreductionofthehip.
Uponconrmationoftheselected
components,removethetrialhead
andtrialneck,andreassemble
thebroachhandletothebroach.
Removethebroachfromthe
femoralcanal.Thenalbroachsize
determinesthecorrectimplantsize.
WARNING
TABLE 4: HeadCompatibility
