Note: The Fowler will not go below 30°
once the Fowler 30°+ lock is activated.
Nurse Controls: Bed Motion Locks
Bed Motion Lock*
Locks all motion on bed, including siderail controls and
foot end controls.
Fowler 30°+ Lock*
Raises the Fowler to 30° and locks out the Fowler control
at all locations.
Patient Fowler Lock*
Locks out Fowler control at all locations, with the
exception of the footboard operator controls.
Patient Gatch Lock*
Locks out Knee Gatch control at all locations, with the
exception of the footboard controls.
Patient Bed Up/Down Lock*
Locks out Bed Height control at all locations, with the
exception of the footboard operator controls.
* Press and hold the lock button to unlock. Button and LED on dashboard will
illuminate when activated.
1
3
4
5
2
1 3 54
2
Always refer to the package insert, product labeling and/or operations
maintenance manuals before using any Stryker product.
11
