101176 REV E 13
Specifications
120V Models 230V Models
Electrical Classification Class I equipment with Type BF applied part suitable for continuous operation. Not
classified for protection against ingress of liquid. Not classified for use in the presence
of flammable anesthetics.
Size (approx.) 11.5” x 8” x 8”
29.2cm x 20.3cm x 20.3cm
Weight 6.5 lbs (2.9 kg) when empty
9 lbs (4.0 kg) with unit filled with water to heating level
Reservoir capacity 93 oz (2.75 l) maximum
Flow rate 7 gph (26.5 lph) minimum with pad attached
Ambient operating
temperature
60°F to 90°F (15.6°C to 32.2°C )
Environmental conditions
for transport and storage
-20°F to 120°F (-28°C to 48°C )
At uncontrolled RH
Temperature setpoints TP650 Classic
107°F (42°C) High heat
100°F (38°C) - Low heat
50°F (10°C) - Cooling
TP700 Professional
107°F (42°C)
100°F (38°C)
95°F (35°C)
50°F (10°C)
TP702
42ºC
38ºC
35ºC
10ºC
Average temperature
accuracy
±2°F at 107°F (±1°C at 42°C)
Maximum Contact
Surface Temperature
107°F (42°C)
High Limit Safety
Temperature
110°F to 120°F
(43.3°C to 49°C)
Power cord International (harmonized) 3-wire cordset Modular
Current leakage 300 microamperes maximum 500µA Max
Ground resistance 0.5 ohm max
Electrical requirements
Voltage (VAC)
Frequency (Hz)
Current (amps)
120±10%
60
3.1 amperes
230+ 10%
50 Hz
1.6 A
Certifications MEDICAL ELECTRICAL EQUIPMENT WITH
RESPECT TO ELECTRICAL SHOCK, FIRE,
AND MECHANICAL HAZARDS ONLY IN
ACCORDANCE WITH UL 60601-1, AND CAN/
CSA C22.2 NO 601.1, ASTM F 2196-2002
EN 60601-1-2
EN 60601-1-2
IEC 60601-1
EN 60601-1
