34 101176 REV E
Replacement Parts List
Item PN Qty Description
1K
100822002 1 KIT: Upper front & Rear Housing. Includes both Front & Rear plastic housing, Label, Membrane Panel
(TP650(c)).
100822001 1 KIT: Upper front & Rear Housing. Includes both Front & Rear plastic housing, Label, Membrane Panel
(TP700(c)).
100822000 1 KIT: Upper front & Rear Housing. Includes both Front & Rear plastic housing, Label, Membrane Panel ( TP702 ).
2K
100898000 1 KIT: PC Board/Sensor Assembly - This assembly comes with a pre-calibrated sensor and PCB assembly. They
are a "Matched" set. Do not use the old sensor with the new PC Board or the old PC Board with the new sensor
( TP650(c), TP700(c)).
100898001 1 KIT: PC Board/Sensor Assembly - This assembly comes with a pre-calibrated sensor and PCB assembly. They
are a "Matched" set. Do not use the old sensor with the new PC Board or the old PC Board with the new sensor
( TP702 ).
3K
100819000 1 KIT: Upper Rear Housing Assembly. Includes Rear Plastic Housing with Label ( TP650(c) ).
100819001 1 KIT: Upper Rear Housing Assembly. Includes Rear Plastic Housing with Label ( TP700(c), TP702 )
4K
100818000 1 KIT: Upper Front Housing Assembly. Includes Front Plastic Housing with Membrane Panel ( TP650(c) ).
100818001 1 KIT: Upper Front Housing Assembly. Includes Front Plastic Housing with Membrane Panel ( TP700(c) ).
100818002 1 KIT: Upper Front Housing Assembly. Includes Front Plastic Housing with Membrane Panel ( TP702 ).
5K
100821001 1 KIT: Heater Assembly. Includes Brass Manifold, 2 O-Rings, 4 Fittings. ( TP650(c), TP700(c) ).
100821000 1 KIT: Heater Assembly. Includes Brass Manifold, 2 O-Rings, 4 Fittings ( TP702 ).
6K 100820000 1 KIT: Reservoir Assembly. Includes Reservoir, Gasket, Rubber Feet, Label.
1 03394000 1 Fitting, Manifold
2 03791001 2 Strap Assembly - Hose
3 04152000 1 Fan
5 08086000 1 Hose Assembly - Clik Tites
6 08648000 6 Hose Assembly - quick disconnects (colder)
7 Source
Locally
3 Tape, Teflon, 1/4" Wide
8 Source
Locally
5 Ty-Wrap, Self Locking
9 81002028 1 Tubing, PVC, Panacea 1/4 ID x 3/8 OD x 3 1/2" LG
10 81002048 1 Tubing, PVC,Panacea 1/4 ID x 3/8 OD x 6" LG
11 90018029 1 Screw, Machine 4-40 x 1/2" FH Phillips
12 90018075 9 Screw Mach PH CR 8-32 UNC 2A x 3/8 LG S
13 90018082 4 Screw, Machine Pan HD #8-32 x 1 SST
14 90049005 2 LockWasher, Spring #6 SST
15 90076018 1 Bushing, Straight Thru (HEYCO #1210)
16 90295019 2 O-Ring
17 90295020 1 O-Ring, Silicone
18 90385000 4 Cup, Suction
19 90514002 3 Screw Type "BT" Thread Cutting Pan HD SST. #4 x 5/16" LG
20 90514013 4 Screw Type "BT" Thread Cutting Pan HD SST. #6 x 7/8" LG
21 90514020 4 Screw Type "BT" Thread Cutting #8 x 3/4" LG
22 90603000 1 Label Ground Identification
23 91275059 1 Screw, Mach, Flat C'Sunk HD, CR SST 6-32 x 3/8 LG
24 91390000 1 Toroid, Ferrite Ring
25 91454052 2 Screw, Mach, Fillister Head #6-32 x 1/4 LG SST
26 100092000 2 Connector Lever Nut 3 Terminal
27 100127000 1 Reservoir
