101176 REV E 35
Replacement Parts List
28 100129000 1 Tray Assembly (TP650(c), TP700(c) )
100129001 1 Tray Assembly ( TP702 )
29 101157000 1 Impeller/Magnet Assembly
30 100132000 1 Impeller Housing Bottom
31 100133000 1 Impeller Housing Top
32 100134000 1 Pin, Impeller
33 100139000 1 Housing, Front Assembly
36 100152000 1 O-Ring, Reservoir
37 100261000 1 Motor/Plate Assembly (TP650(c), TP700(c) )
100261001 1 Motor/Plate Assembly (TP702 )
38 100267000 1 Cord, Power Assy (TP650(c),TP700(c) )
39,40 100269001 1 Membrane Panel - Professional (TP700(c) )
100269002 1 Membrane Panel - Classic (TP650(c) )
100269003 1 Membrane Panel - CE ( TP702 )
41 100275000 1 Cap, Tethered, Rivet Assembly
42 101158000 1 Magnet Driver Assembly (Not Shown)
43 100288000 1 Label, Instruction Classic (TP650 )
44 100288001 1 Label, Instruction Professional (TP700 )
45-48 100289000 1 Label, Ratings Classic (TP650 )
100289001 1 Label, Ratings Professional (TP700 )
100289002 1 Label, Ratings Classic W/quick disconnects (TP650c )
100289003 1 Label, Ratings Professional W/quick disconnects (TP700c )
100289004 1 Label, Ratings CE Professional (TP702 )
49 100292000 1 Clip, Cord
50 100378000 1 Cap (for Impeller Pin)
51 100578000 1 Label, Danger
52 100256002 1 Heater Assembly 230 VAC (TP702)
100256001 1 Heater Assembly 120 VAC
53
PC001 1 Power Cord (Continental Europe) - (TP702)
PC002 1 Power Cord (United Kingdom) - (TP702)
PC003 1 Power Cord (Australia) - (TP702)
To Next Page
