Xtender information description
Dynamic compensation of battery voltage
Temperature compensation of battery voltage
Operating state (----, Inverter, Charger, Boost, Injection)
Discharge of battery of the previous day
Discharge of battery of the current day
Remote entry state (RM EN 0, RM EN 1)
Source of limitation of the functions charger or injector (----,
Ubatt, Ubattp, Ubattpp, Ibatt, Pchar, UbattInj, Iinj, Imax, Ilim,
Ithermal, PchNeg)
Over temperature state (No Error, TR.Alarm, TR.Error, EL.Error, EL.Stop)
Energy AC-In from the previous day
Energy AC-In from the current day
Desired AC injection current
AC injection current limited (ARN4105)
AC injection current, type of limitation (ARN4105) (No limit,
Freeze, NotImax)
Consumers energy of the previous day
Consumers energy of the current day
State of transfer relay (Opened, Closed)
State of output relay (Opened, Closed)
State of auxiliary relay 1 (Opened, Closed)
State of auxiliary relay 2 (Opened, Closed)
Relay aux 1 mode (----, A, I, M, M, G)
Relay aux 2 mode (----, A, I, M, M, G)
Input limite reached (Off, On)
Battery priority active (Off, On)
Forced grid feeding active (Off, On)
