Studer RCC-02 Quick Guide

Studer Innotec SA
Quick guide RCC-02/-03
38 V 6.1.0 Quick guide
Nr
Message
Troubleshoot
132
(132): The VarioTrack is configured for
24V batteries
After detection of a 24V battery, this message is
sent when an RCC is connected to the system.
133
(133): The VarioTrack is configured for
48V batteries
After detection of a 48V battery, this message is
sent when an RCC is connected to the system.
134
(134): Reception level of the GSM signal
Indication of the GSM signal level in the Xcom-GSM
137
(137): VarioTrack master
synchronization lost
No VarioTrack synchronization signal for 10s. The
device continues to operate with its own charge
profile. Check the communication cables and the
terminations of the communication bus.
138
Error (138): XT master synchronization lost
No synchronisation with the Xtender for 10 s.
139
(139): Synchronized on VarioTrack
master
Sent after receiving the first frame of
synchronization with the VarioTrack.
140
(140): Synchronized on XT master
Sent after receiving the first frame of
synchronization with the Xtender.
141
Error (141): More than 1 Xcom-SMS in
the system
See troubleshoot nr 92
142
Error (142): More than 15 VarioString in
the system
See troubleshoot nr 92
143
(143): Save parameter Xcom-SMS
See troubleshoot nr 63
144
(144): Save parameter VarioString
See troubleshoot nr 63
145
Error (145): SIM card blocked, PUK
code required
SIM card blocked. PUK required. To unblock SIM card,
a mobile phone should be used to enter the PUK.
146
Error (146): SIM card missing
Missing SIM card
147
Error (147): Install R532 firmware
release prior to install an older release
If you want to install a release prior to the R532
release, you must first install the R532 release.
148
(148): Datalogger function
interrupted (SD card removed)
Since the SD card is not present, there will not be
any datalogs saved to the SD card at midnight
each day.
149
Error (149): Parameter setting
incomplete
The directory containing the parameters of the
device in operation does not contain all the
necessary files.
150
Error (150): Cabling error between PV
and VarioString
Check that the cable connections of the PV
modules corresponds to the type of cabling set in
parameter settings.
162
Error (162): Communication loss with
RCC or Xcom-232i
The device does is not communicating on the
CAN bus. Check the communication cable and
the connection to the battery of all devices.
163
Error (163): Communication loss with
Xtender
See troubleshoot nr 162
164
Error (164): Communication loss with
BSP
See troubleshoot nr 162
165
Error (165): Communication loss with
Xcom-MS
See troubleshoot nr 162
166
Error (166): Communication loss with
VarioTrack
See troubleshoot nr 162
167
Error (167): Communication loss with
VarioString
See troubleshoot nr 162
168
(168): Synchronized with VarioString
master
Sent after receiving the first frame of
synchronization with VS.

Studer RCC-02 Specifications

General

Brand	Studer
Model	RCC-02
Category	Remote Control
Language	English
