R134a R410A
bar 0,5 3,0
bar 1,5 6,0
bar 24,5 36,0
bar 18,0 29,0
bar 28 40
EN
Adjustment of the pressure switches:
LP switch:
releases at:
automatic reset at:
HP switch:
releases at:
manual reset possible at:
Safety valve:
Design conditions for A/C units:
Electrical connection:
Return air conditions for evaporator capacity:
with an external static pressure:
400V/3ph/50Hz
33°C, 30% rel. h.
20 Pa
Cooling fluid circuit GE, GES
Cooling fluid water, 30% ethylen glycol
Fluid temperature inlet/outlet (summer operation) 34°C/40°C
Water temperature inlet (winter operation) 11°C
Condensation temperature 45°C
The sound pressure levels are valid at a height of 1m and distance of 2m in front of the unit under free field condi-
tions and with nominal data. The values take into account the effects of all installation and design parts contained
in the standard unit.
