Commissioning
The reheats are controlled and monitored by the controller of your A/C unit. No further measures are required for
commissioning.
Installation
The reheats are installed and connected in the A/C unit. The HW reheat is to be connected on site to the external
hot water circuit. The pipelines are to be routed out of the A/C unit. The thread sizes for the connection piping of
the HW reheat are listed in the following table.
Malfunction causes
Alarm: Reheat defect
All reheat alarms are received by the controller and can be requested according to the equipment.
C7000-control system: no display (display only externally)
C7000 advanced terminal: indication on the display
C1002: display: HEA
Cabinet size
Pipe - Ø mm
Thread size inch
Temperatures:
Water inlet: 60°C
Water outlet: 40°C
Air inlet: 13°C
Glycol: 0%
1 2 3 4 5 7
16 22 22 22 22 22
1/2 3/4 3/4 3/4 3/4 3/4
