E/0310/50/16
Item
8
9
10
11
a. CW-units
Valve Modulating Time
Modulating time of CW-valve (operating level
0% up to operating level 100% in seconds)
will be entered in this menue point.
Actuator SQS 82, SQS 81 (L&G): 150 se-
conds.
CW valve Start Value
CW valve Proportional Range
Start point Cooling and proportional range
of CW- valve are entered in these points of
menue. Refer to control scheme.
Opening degree for dehumidification
Opening degree of CW-valve required for de-
humidification can be entered in this item.
Maximum opening degree for dehumi
-
di-fication can be passed over when the
CW-valve´s opening degree for cooling is
increased.
b. Units with Compressor
Compressor Restart Delay
In this item the restart delay in seconds is
entered. After a compressor shut down, it
can only be restarted when the time set has
elapsed.
1. Compressor Start Value
Hysteresis of Compressors
2. Compressor Start Value
The parameters of the compressors' start
and hysteresis can be entered in these menu
items (9b-11b).
Menu item 11b is only relevant, if a second
compressor exists.
If the proportional range or hysteresis is set to actual value "0" the corresponding function is not
required, the status- LED is not activated and the corresponding failures are not evaluated.
