Stulz CyberCool 2 - Page 54

54
Mxl Mxr
Modell M1 M2 M3 M4 M5
ESO 4702 A...N kg 550 748 785 830 326
ESO 5102 A...N kg 550 754 804 847 327
ESO 6002 A...N kg 660 904 863 841 329
ESO 6602 A...N kg 660 911 882 859 331
ESO 4702 A...F kg 602 869 1001 1024 504
ESO 5102 A...F kg 570 865 1017 1040 552
ESO 6002 A...F kg 726 1024 973 1033 604
ESO 6602 A...F kg 724 1013 1046 1054 568
EQO 3002 A...N kg 522 709 780 838 287
EQO 3302 A...N kg 522 716 799 856 289
EQO 3702 A...N kg 528 719 790 848 291
EQO 4002 A...N kg 529 727 810 866 294
EQO 3002 A...F kg 539 810 994 1052 503
EQO 3302 A...F kg 540 818 1013 1050 526
EQO 3702 A...F kg 545 820 1004 991 578
EQO 4002 A...F kg 546 828 1023 1050 540
M1 M2 M3 M4 M5
EN/09.2019/G41 © STULZ GmbH – all rights reserved
cybercool 2 screw original insTrUcTions
Construction size 2
The weights are indicated with a tolerance of ±5%.
Model
The weight on the support Mxr (M1, M2, M3 ... M5) is
equal to the weight on the support Mxl.
