75
Modell Vmin [m³/h]
E_O 4702 A__ 30
E_O 5102 A__ 30
E_O 6002 A__ 35
E_O 6602 A__ 40
E_O 7402 A__ 45
E_O 8002 A__ 50
E_O 8702 A__ 55
Modell Vmin [m³/h]
E_O 9602 A__ 60
E_O 10202 A__ 65
E_O 11102 A__ 70
E_O 11502 A__ 75
E_O 12602 A__ 80
E_O 13102 A__ 85
E_O 14102 A__ 90
© STULZ GmbH – all rights reserved EN/09.2019/G41
cybercool 2 screw original insTrUcTions
6.6 Commissioning of the refrigerant circuits
the technical data.
-
pressor and points to the condenser coils. After having removed the compressor cabinet panels of the left
unit side it can be read with the help of an electric torch and a mirror angled by 45 degrees.
The oil level should be between the lower quarter and the upper quarter of the sight glass.
comp 2 hand 1
comp 2 handon 0
value for standard operation. A speed controlled pump can not be controlled by the C7000 controller and
requires an external control.
Setting the minimum water volume flow
The following triggering values for the minimum volume flow have been adjusted in the factory:
red LED
adjusting
screw
flow sensor module
You can modify the triggering value for the water flow alarm at the flow sensor module (illustration right) in the
electric cabinet by means of a little screw driver.
If the flow rate is slightly lower, the red LED lights up fully and the water flow alarm is triggered.
long downtime and adapt it to the prevailing load conditions.
state start.
circuit in manual mode and by producing a cooling capacity request (providing approx. 18°C warm water
chilled water inlet of the chiller or by setting the water temperature setpoint sufficiently low).
this is the case, refrigerant might have escaped by a leak.
"Maintenance".
Model Vmin [m³/h] Model Vmin [m³/h]
