Stulz CyberCool 2 - Page 57

57
M1 M2 M3 M4 M5 M6 M7
Modell M1 M2 M3 M4 M5 M6 M7
ESO 9702 ASN kg 834 1121 933 767 706 553 250
ESO 9802 ASN kg 832 1121 952 822 719 548 249
ESO 9702 A...F kg 865 1236 1142 1037 983 836 393
ESO 9802 A...F kg 862 1235 1160 1092 996 830 392
ESO 9702 AHN kg 844 1135 939 767 705 553 250
ESO 9802 AHN kg 842 1135 958 822 719 548 249
Mxl Mxr
© STULZ GmbH – all rights reserved EN/09.2019/G41
cybercool 2 screw original insTrUcTions
Construction size 3½
The weights are indicated with a tolerance of ±5%.
Model
The weight on the support Mxr (M1, M2, M3 ... M7) is
equal to the weight on the support Mxl.
