59
Modell M1 M2 M3 M4 M5 M6 M7 M8
ESO 13102 A...N kg 961 1028 1019 990 922 651 595 411
ESO 14102 A...N kg 965 1031 1023 1004 936 665 609 455
ESO 13102 A...F kg 988 1063 1056 1055 1062 1055 1049 935
ESO 14102 A...F kg 1003 1068 1071 1070 1077 1070 1065 950
EQO 10202 A...N kg 944 963 994 939 906 667 635 438
EQO 11102 A...N kg 951 978 1008 951 920 685 652 444
EQO 10202 A...F kg 1119 1083 1144 1060 1053 969 904 837
EQO 11102 A...F kg 1126 1100 1160 1067 1060 986 921 855
M1 M2 M3 M4 M5 M6 M7 M8
Mxl Mxr
© STULZ GmbH – all rights reserved EN/09.2019/G41
cybercool 2 screw original insTrUcTions
The weights are indicated with a tolerance of ±5%.
Model
Construction size 5
The weight on the support Mxr (M1, M2, M3 ... M8) is equal to the weight on the support Mxl.
