cybercool 2 screw original insTrUcTions
Electrical cabinet power section, left side
Compressor
power switch
circuit 1
Compressor
power switch
circuit 2
Main switch
Condenser fan power
switch circuit 1
Condenser fan power
switch circuit 2
Control circuit fuses
PE rail
Neutral terminal
Power supply
Compressor power switch
in position "off"
