Positioning of the stove
Caution !
For perfectly smooth tilting of the
door, masonry must be level with the
base of the hearth opening [photo1].
Connection to the smoke flue
The fitting of the various flue parts
must be air-tight to encourage
the dispersal of condensation
[diagram1A] rather than that of the
smoke [diagram 1B].
In the case of a connection duct for
just one room, leave a gap of 2mm/m
lengthways to allow for expansion.
Fit the smoke outlet (high or low as
suitable) [photo5ou6].
Locating the glass protection and smoke outlet (continuation)
