Stûv 21 - installation [en] - 04-2013
Lining the combustion chamber (continuation)
Position the spacer pieces (A) after
layers 2 and 3.
In all double-face models :
Position and centre all refractor plates
on the back wall, then those on the
side walls.
Stûv 21/75 SF, 21/85 SF, 21/95
SF, 21/105 SF
The refractory bricks are available in a
choice of two shades: light or dark.
