Electronic Control System
Wine Storage
Wine Storage
(400-
(400-
2
2
)
)
Series
Series
3-12
#3758410 - Revision C - May, 2014
Monitor and Control Off-cycle Defrost
Since High Offset (Cut-in) is governed by the evaporator temperature, the refrigeration system cannot be energized
until evaporator temperatures exceed 39°F / 4°C, with a 38°F/3°C set-point, and/or exceed 66°F / 19°C, with a
65°F/18°C set-point.
Figure 3-18. Off-cycle Defrost Signal Trace
N.O.
N.O.
N.C.
To Next Page
