MODEL 427R-2 REFRIGERATOR SECTION CONTROL PANEL LAYOUT
NOTE: The LCD is not back lit. It will appear darker than the LED’s in the wine section.
UNIT
REFRIGERATOR
ON/OFF
ON/OFF
WARMERCOLDER
OFF
SERVICE
Figure 3-45. 427R-2 Refrigerator Control Panel Layout
REFRIGERATOR SET-POINT
ADJUSTMENT KEYS
LCD
(Liquid Crystal Display)
DRAWER AJAR
ALARM ON/OFF KEY
UNIT
ON/OFF KEY
