Sub-Zero Mega Chill User Manual

NO.
1.
2.
3.
4.
QTY
1No.
1No.
4Nos.
1No.
ITEMS
TOROIDAL TRANSFORMER WITH SCREW
(I/P: 0-230V, O/P1: 0-9V @0.35A, O/P2: 0-10V @0.5A)
CATALOG
PROKEY
SCREWS (4X12)
5.
2Nos.
NTC SENSORS (1.5m)
6.
1No.
COMMUNICATION CORD(2m)
LIQUID LEVEL SENSORS (2m)
OR
LIQUID LEVEL SWITCH
2
3
1. Accessaries in Box
Items Included
Specifications are subject to change due to continuous improvements of
our products. No consequential damage or field labour is included in the
sales of products mentioned in this manual. The manufacturer is not
liable for incorrect use/misuse of the product mentioned.
A.S. Controls Pvt Ltd. All rights reserved Sub-Zero and the Sub-Zero logo are
registered trademarks of A.S. Controls Pvt Ltd.
NO.
1.
QTY
3Nos.
ITEMS
Optional Items
NTC SENSORS (1.5m)
2.
4Nos.
2 COMPRESSOR2 COMPRESSOR

Sub-Zero Mega Chill Specifications

Operating Environment

operating temperature	-50 C to +50 C0
storage temperature	-20 C to + 70 C
operating humidity	Max 80% (non-condensing)
storage humidity	Max 80% (non-condensing)

Power

max continuous input voltage	230 Vac
input current (closed contact)	10 mA
transformer primary input	230Vac, 50Hz
transformer secondary output 1	9Vac, 350mA
transformer secondary output 2	10Vac, 500mA

Digital Output (Relay)

type	SPDT
contacts	C & NO (C, No, NC for compressor)
rating	250 Vac, 5A(resi)

Analog Inputs

sensor type	Japanese NTC thermistors
specification	10K @ 25 C0
resolution	0.5 C0
accuracy	+/- 1 C0
