Fuse
panel
Fuse
rating
Circuit
13 20A
. Cargo socket
14 15A
. Position light
. Tail light
. Rear combination light
15 Empty
16 10A
. Illumination
17 15A
. Seat heaters
18 10A
. Back-up light
19 7.5A
. Headlight right side re-
lay
20 10A
. Cigarette lighter socket
21 7.5A
. Starter relay
22 15A
. Air conditioner
. Rear window defogger
relay coil
23 15A
. Rear wiper
. Rear window washer
24 15A
. Audio unit
. Clock
25 15A
. SRS airbag system
26 7.5A
. Power window relay
27 15A
. Blower fan
Fuse
panel
Fuse
rating
Circuit
28 15A
. Blower fan
29 15A
. Fog light
30 30A
. Front wiper
. Front wiper washer
31 7.5A
. Auto air conditioner unit
. Integrated unit
32 7.5A
. Headlight left side relay
33 7.5A
. ABS/Vehicle dynamics
control unit
Specifications
12-7
